Maximise productivity with a fast print speed of up to 416 characters per second (12 cpi).
Meet the new tireless performer in your business, the Epson LQ-1310. This 24-pin wide carriage printer, prints at a lightning fast speed of 416 CPS (12 CPI) and has a choice of 8 built-in barcode formats for maximum versatility. Get an exceptional print head life of 400 million strokes/wire and an unmatched reliability of 10,000 POH (Power On Hours), along with connectivity options like the built-in USB, Serial and Parallel Interface. Employ the 24/7 original worker for the perfect printing solution for your business.
| Functions | |
| Technology | Impact dot matrix |
| Number of Pins | 24 pins |
| Speed | Print Speed : 10 / 12 cpi , 347 / 416 cps , Draft : 10 / 12 / 15 cpi 260 / 312 / 390 cps, Condensed : 17 / 20 cpi 222 / 260 cps, LQ : 10 / 12 / 15 cpi, 86 / 103 / 129 cps |
| MTBF | Approx. 10,000 POH (25% Duty) |
| Print Head Life | Approx. 400 million strokes/wire |
| Character Sets | 14 international character set ; 13 Character Tables + 5 Indian Tables; Italic, PC 437, PC850,PC 860, PC 861, PC 863, PC 865, Abicomp, BRASCII, Roman 8, ISO Latin 1, PC 858, ISO 8859-15, ISCII, PC ISCII, EA ISCII, TAB TAMIL 99, TAM TAMIL 99 |
| Supported Bitmap Fonts | Epson Draft: 10, 12, 15 cpi; Epson Roman & San Serif: 10, 12, 15 cpi, Proportional; Epson Courier: 10, 12, 15 cpi; Epson Prestige: 10, 12 cpi; Epson Script, OCR-B, Orator & Orator-S: 10cpi; Epson Script C: Proportional Indian font (Proportional) : CDAC D |
| Supported Scalable Fonts | Epson Roman, Epson San Serif, Epson Roman T & Epson San Serif H: 10.5pt., 8pt. - 32pt.(every 2pt.) |
| Barcode Sets | EAN-13, EAN-8, Interleaved 2 of 5, UPC-A, UPC-E, Code 39, Code 128, Postnet |
| Media Cut Sheet | Cut Sheet (Manual Insertion) Length : 100 ~ 364mm, Width : 148 ~ 420 mm, Thickness : 0.065 ~ 0.14 mm |
| Continuous Paper | Manual Insertion : Top in, Top out ; Push Tractor, Pull Tractor, Cut Sheet Feeder : Rear in, Top out |
| Multipart Copy | Original + 3 copies |
| Print Direction | Bi-directional with logic seeking |
| Emulation | ESC/P2 and IBM PPDS emulation |
| Memory | Data Buffer: 128KB |
| Supported Consumables | Ribbon Cartridge (Black) : 3 million characters S015634 |
| Interface | Bi-directional parallel interface (IEEE-1284 nibble mode supported) Serial Interface; USB 2.0 Full Speed |
| Control Panel | 4 switches and 5 LEDs |
| Voltage | AC 120V / AC 220 - 240V |
| Rated Frequency | 50Hz ~ 60Hz |
| Power Consumption | Approx. 24W (ISO/IEC 10561 Letter pattern), (ENERGY STAR compliant) |
| Environment | Temperature : 5 ~ 35°C , Humidity : 10 ~ 80 % RH |
| Dimension | 537 x 355 x 199 mm (Width x Depth x Height) |
| Weight | 6kg |
Meet the new tireless performer in your business, the Epson LQ-1310. This 24-pin wide carriage printer, prints at a lightning fast speed of 416 CPS (12 CPI) and has a choice of 8 built-in barcode formats for maximum versatility. Get an exceptional print head life of 400 million strokes/wire and an unmatched reliability of 10,000 POH (Power On Hours), along with connectivity options like the built-in USB, Serial and Parallel Interface. Employ the 24/7 original worker for the perfect printing solution for your business.
