Dot Matrix Printer-printed fast, reducing waiting time with long life reliability.
YOU’LL APPRECIATE OUR FASTEST PRINTER IN NO TIME
| Functions | |
| Technology | Impact Dot Matrix, Color: Black |
| Number of Pins | 9 Pins |
| Speed | High Speed Draft: 12 cpi, 1450 cps, Draft 12 cpi, 1320 cps, NLQ 12 cpi, 330 cps |
| MTBF | 20,000 POH (25% Duty Cycle) |
| Print Head Life | 200 Million Strokes/Wire |
| Standard Character | Italic Table, PC437(US,Standard Europe), PC850(Multilingual), PC860(Portuguese), PC863(Canadian-French), PC865(Nordic), PC861(Icelandic), BRASCII, Abicomp, Roman 8, ISO Latin 1, PC858, ISO 8859-15 |
| Supported Bitmap Fonts | Epson: High Speed Draft, Draft, Roman, Sans Serif |
| Barcode Sets | EAN-13, EAN-8, Interleaved 2 of 5, UPC-A, UPC-E, Code 39, Code 128, Postnet |
| Continuous Paper | Width 76.2 – 419.1 mm (3.0 – 16.5 Inch), Length 76.2 – 558.8 mm (3.0 – 22.0 Inch), Thickness 0.065 – 0.10 mm (0.0025 – 0.0039 Inch) |
| Multipart Copy | 1 Original + 9 Copies (Front), 1 Original + 6 Copies (Rear) |
| Print Direction | Tractor (Front or Rear In, Top Out) Bi-Direction with Logic Seeking |
| Emulation | ESC/P®, IBM® PPDS Emulation |
| Memory | 128 kbytes |
| Supported Consumables | Fabric Ribbon Cartridge, Color : Black: Ribbon Life: 15 million characters (Draft 10 cpi, 14 Dots/Character) |
| Interface | Bi-Directional Parallel Interface (IEEE-1284 Nibble Mode Supported, Serial I/F, USB (Ver.1.1) I/F, Type B I/F Level 2 (Option) |
| Control Panel | 9 buttons, 6 LEDs and 1 LCD, Noise: 58 dB(A) (ISO 7779 Pattern) |
| Voltage | AC 100 - 240 V |
| Rated Frequency | 50 - 60Hz |
| Power Consumption | Approx. 185W (ISO/IEC 10561 Letter Pattern), Approx. 7.5 W in Sleep mode, Energy Star Compliant |
| OS Compatibility | Microsoft®Windows®95/98/2000/Me/XP and Microsft®Windows®NT®Operating System Version 4.0 |
| Environment | Temperature 5 ~ 35°C Humidity 10 ~ 80% RH |
| Dimension | Width-700 mm x Depth 378 mmx Height 363 mm |
| Weight | Approx. 34 kg |
