| Country of Origin |
USA |
| Model |
Cisco ME 3600X-24TS |
| Ethernet/RJ-45 Ports |
10/100/1000 BASE-T ports, DB9 cable for PC connections |
| SFP/Uplink Port |
GLC-FE-100FX, GLC-FE-100EX, GLC-FE-100ZX, GLC-FE-100LX, GLC-FE-100BX-U, GLC-FE-100BX-D, GLC-LHSM, GLC-SX-MM, GLC-ZX-SM, GLC-T, CWDM-SFP-1470, CWDM-SFP-1490, CWDM-SFP-1510, CWDM-SFP-1530, CWDM-SFP-1550, CWDM-SFP-1570, CWDM-SFP-1590, CWDM-SFP-1610, GLC-BX-U, GLC-BX-D, SFP-GE-L, SFP-GE-S, SFP-GE-T, DWDM-SFP-xx, CAB-SFP-50CM |
| Bandwidth |
Forwarding: Cisco ME 3600X-24TS AC or DC: 44 Gbps |
| Forwarding Rate |
Cisco ME 3600X-24TS AC or DC: 65 Mpps |
| Memory |
DRAM: 1GB, Flash: 64MB, |
| MTBF |
ME3600X-24TS-M: 205,863 hours, PWR-ME3KX-DC: 319,000 hours (48V input at 40ºC), PWR-ME3KX-AC: 328,000 hours (120V at 40ºC), 342,000 hours (230V at 40ºC), ME-FANTRAY: 2,177,000 hours (12V input at 40ºC), LpA: 43 dB typical, 46 dB maximum, LwA: 5.4 Bel typical, 5.6 Bel maximum |
| Power |
AC Input Voltage: 100 to 240 VAC, Frequency: 50 to 60 Hz, DC input voltages : 18V to 32VDC, 36V to 72VDC, Power Consumption: Cisco ME 3600X-24TS, one AC and one fan tray: 150W, (typical), 192W (maximum), 512 Btus per hour (typical), 656 Btus per hour (maximum) |
| Standards |
IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports, IEEE 802.1D Spanning Tree Protocol, IEEE 802.1p CoS classification, IEEE 802.1Q VLAN, IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-T, IEEE 802.3ab 1000BASE-T, IEEE 802.3z 1000BASE-X, BFD for OSPF, IS-IS, BGP, HSRP, EIGRP, IP routing: Static, RIP versions 1 and 2, EIGRP, OSPF, BGPv4, PIM-SM, and PIM-DM (metro IP access only), Management: SNMP versions 1, 2, and 3 |
| Routing |
Pv4 Routing (Border Gateway Protocol [BGP], Intermediate System-to-Intermediate System [IS-IS], and Open Shortest Path First [OSPF]), Hot, Standby Router Protocol (HSRP), Virtual Router Redundancy Protocol (VRRP) |
| Packet Buffer |
44MB |
| Protocol |
Simple Network Management Protocol (SNMP), Layer 2 Protocol Tunneling (L2PT) |
| Cabling Type |
SFP-10G-SR, SFP-10G-LR, SFP-10G-ER, SFP-10G-LRM, SFP-H10GB-CUxM where x = 1, 3, 5 meters |
| Control Panel |
Per-port status LEDs: Link integrity, port disabled, and activity indications, Power input /output status LED, Alarm status LED, SynchE status LED, System-status LED |
| Safety |
UL 60950-1, UL to CAN/CSA 22.2 No.60950-1, TUV/GS to EN 60950-1 with all Amendments, CB to IEC 60950-1 with all country deviations, NOM to NOM-019-SCFI (through distributors) CE Marking, CCC. NEBS: GR-63-CORE, GR-1089-CORE – Level 3, Type 2, Verizon’s FOC Certification on o1ptical SFPs, ETSI: EN 300 019 – Storage: Class 1.2, Transportation: Class 2.3, In-Use: Class 3.2 |
| Environment |
Temperature: Opearting: 0 to +50ºC (1000 feet), 0 to +45ºC, up to 6000 feet, Altitude: 0 to +40ºC, up to 10,000 feet, Storage: Temperature: –25 to +70ºC altitude: 15,000 ft, Relative Humidity: 5% to 95%, non-condensing |
| Advanced Features |
Project management, Site survey, configuration, and deployment, Installation, text, and cutover, Training, Major moves, adds, and changes, Design review and product staging |
| Weight |
6.41 Kgs |
| Dimension |
All SKUs 1.72-in. x 17.50-in. x 20.33-in. (H x W x D) |
