Cisco Catalyst 3850 12 Port 10g,Fiber Switch IP Services

It delivers Power over Ethernet Plus(PoE+) that supports up to 740W of PoE budget for 24 ports with 30W per port or 48 ports with 15.4W per port.

Model	WS-C3850-12XS-E
WAN/LAN Ports	12 x 10/100/1000 10G SFP+ Optical ports
Ethernet/RJ-45 Ports	1 CONSOLE (RJ-45 console port)
SFP/Uplink Port	Network SFP uplink module slot
Slots	1 network module slot and 1 power redundant slot
Bandwidth	Stack Bandwidth : 480Gbps
Forwarding Rate	Forwarding Performance : 227.28Mpps
Switching Capacity	320Gbps
MAC Address	MAC Address Table Size : 32K
VLAN	Maximum VLANs IDs : 1,000
Memory	RAM : 4 G ; Flash Memory : 4 G
MTBF	371,440 hours
Power	Power supply : PWR-C1-350WAC ; Power Device : Power supply - redundant - plug-in module ; Power Redundancy : optional ; Voltage range (Auto) : 100V-240V ; Power Consumption of standalone(in Watts) : 109.75 (Max)
Standards	IEEE 802.1D Spanning Tree Protoco , IEEE 802.1p CoS Prioritization , IEEE 802.1Q VLAN , IEEE 802.1s , IEEE 802.1w , IEEE 802.1X , IEEE 802.1X-Rev ,IEEE 802.11 , IEEE 802.1ab (LLDP) , IEEE 802.3ad , IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports , IEEE 802.3 10BASE-T , IEEE 802.3u 100BASE-TX , IEEE 802.3ab 1000BASE-T , IEEE 802.3z 1000BASE-X , RMON I and II standards , SNMP v1, v2c, and v3

Review is not available now!

To download flyer, brochure or specification of Cisco Catalyst 3850 12 Port 10g,Fiber Switch IP Services , click the on the buttons. (All documents are pdf format)

Flyer

Brochure

It delivers Power over Ethernet Plus(PoE+) that supports up to 740W of PoE budget for 24 ports with 30W per port or 48 ports with 15.4W per port.

Cisco Catalyst 3850 12 Port 10g,Fiber Switch IP Services
