| Model Size |
24” |
| Functions |
Print |
| Technology |
Canon Bubble-jet On Demand (12 channels integrated type x 1 print head) |
| Print Direction |
Dual direction roll take up unit |
| Speed |
Plain Paper: (Level 5) A1 Size-0:58,A0 Size-01:37 ; (Standard) A1 Size - 1.37, A0 Size- 2.51 ; High : (A1 Size) 3:11, A0 Size-5:36 ; Coated Paper1 : (Standard) : A1 Size-01:37; A0 Size-02:51 , High : A1 Size-03:12, A0 Size-05:36 ; Photo Glossy Paper : (Standard): A1 Size-03:34, A0 Size-06:21 |
| Nozzle Configuration |
18,432 nozzles (1,536 nozzles x 12 colour) ; 600 dpi x 2 (includes non-firing nozzle detection and compensation system) |
| Memory |
3 GB |
| Hard Disk Drive |
320 GB |
| Resolution |
2400 dpi x 1200 dpi |
| Ink Type |
Pigment inks - Photo Black, Matte Black, Cyan, Magenta, Yellow, Photo Cyan, Photo Magenta, Grey, Photo Grey, Red, Blue, ChromaOptimiser ; Capacity : Sales Ink: 160ml/330ml/700ml, Bundled Starter Ink: 160ml |
| Cartridges Number |
12 Colour |
| Ink Supply System |
Ink Capacity : Sales Ink: 160ml/330ml/700ml, Bundled Starter Ink: 160ml |
| Roll Media Handling |
Roll Paper: One Roll, Front-loading, Front Output Optional Roll Paper: One Roll, Front-loading, Front Output Cut Sheet: Front-loading, Front Output (Manual feed)Roll Paper : One roll. If second option is added then automatic switching is possible Cut Sheet: 1 sheet |
| Media Thickness |
Roll/Cut: 0.07 ~ 0.8 mm |
| Line Accuracy |
±0.1% or less User adjustments necessary. Printing environment and media must match those used for the adjustments. |
| Control Panel |
Display LCD : 3.5 inch/8.8 cm TFT colour |
| Network |
Standard : IEEE 802.3 10base-T, IEEE 802.3u 100base-TX / Auto-Negotiation,IEEE 802.3ab 1000base-T / Auto-Negotiation, IEEE 802.3x Full Duplex |
| Interface |
USB A Port :(Type) USB Memory (Direct Print); USB B Port : (Type) Built-in (Hi-Speed USB), Mode : Full Speed (12 Mbit/sec), High-Speed (480 Mbit/sec), Bulk transfer ; Connector type : Series B (4 pins) |
| Voltage |
AC 100-240V (50-60Hz) |
| Power Consumption |
Operation: 88 W or less, Standby: 1.8 W or less, Power off: 0.5 W or less |
| OS Compatibility |
Microsoft Windows 32 Bit: Vista, 7, 8, 8.1, 10, Server 2008, 64 Bit: Vista, 7, 8, 8.1, 10, Server 2008/R2, Server 2012/R2 Apple Macintosh: OSX 10.7.5 ~ 10.11 |
| Included Accessories |
Printer, 1 x print head, 3” paper core attachment, EU & UK Power Cable, 1 set of starter ink tanks, Set up guide, Safety/StandardEnvironment leaflt, User software CD-ROM (OSX/Windows), PosterArtistLite CD-ROM, EU Biocide Sheet, Eurasian EconomicUnion Sheet, Important Information Sheet, Quick Guide and Printhead Alignment Sheet |
| Certification |
RoHS |
| Noise Level |
Operation: 48 dB (A) (Glossy paper, Print priority: Standard), Standby: 35 dB (A) or less Operation: 6.4 Bels or less,(Glossy paper, Image, Print priority: Standard) (Measured on ISO7779 standard) |
| Network Protocols |
SNMP [Canon-MIB, HTTP, TCP/IP (IPv4/IPv6)] |
| Language Supported |
SGRaster (Swift Graphic Raster) ; 16 Languages Selectable: Japanese/English/German/Italian/Spanish/Brazilian portuguese/Dutch/Polish/Russian/Danish/Simplified Chinese/Traditional Chinese/Korean/Thai/Indonesian/Turkish |
| Dimension |
Printer W x D x H : (main unit with pallet) 1110 x 766 x 1168 mm |
| Shipping Dimension |
Printer W x D x H : (main unit with pallet) 1324 x 902 x 1045 mm |
| Weight |
129 kg |
